Passing H12-323_V2.0 exam is a required step for earning HCIP-WLAN certification. Learning H12-323_V2.0 exam information is the first step to study. There are 60 Single-answer Question, Multiple-answer Question, True or false, Short Response Item, Drag and Drop Item in real H12-323_V2.0 exam, and you have 90 minutes to answer all the questions. The required passing score is 600. The exam cost is $300. The available languages are English and Chinese. We provide the latest HCIP-WLAN V2.0 H12-323_V2.0 exam dumps, which are valuable for you to pass the test easily. Free HCIP-WLAN V2.0 H12-323_V2.0 exam dumps are available below.

Page 1 of 20

1. The CloudCampus APP mainly includes two functional modules: network and tools.

Which of the following descriptions of the functions under the tool module is wrong?

Check terminal: obtain information about illegally accessed terminals

Wi-Fi status: You can view the current Wi-Fi status information, such as signal strength, channel, negotiation rate, etc.

Game test: Test network jitter and packet loss rate

Test network speed: only supports Internet speed test

2. A user views the domain management template information on WAC as follows. Which of the following descriptions is wrong?

The current 4.9G frequency band is not enabled

The current country code is China's country code. If you want to change it, you can use the command country-code to configure it.

The current 5G RF tuning bandwidth is 20 MHZ

The current channel loading mode is outdoor mode

3. When there are many users in the WLAN network, such as in high-density scenarios, as the number of online users increases, the fierce competition for channels between users leads to poor Internet access quality for each user. In order to ensure the Internet access experience of online users, the user connection admission control (CAC) function can be deployed.

Which of the following descriptions about the user CAC function is wrong?

CAC uses two thresholds to control the access of new users and roaming users respectively.

When a roaming user accesses the radio, the roaming user can access the radio as long as the roaming user threshold is not reached.

When most users use the same service type and the service traffic is average, it is recommended to use the user CAC function based on terminal SNR

When a new user accesses, the AP checks whether the current number of users or the terminal signal-to-noise ratio reaches the threshold for new users. If so, the new user's access is denied and the SSID can be hidden.

4. CampusInsight supports application analysis, monitors network-wide applications, and visualizes overview data such as application numbers and traffic. This function relies on the device reporting traffic statistics to CampusInsight, which supports two types of traffic statistics reporting: NetStream-based reporting and application-based reporting.

When selecting application-based reporting, which of the following functions needs to be enabled on the wireless controller?

DFI

RF Tuning

SAC

DA channel scan

5. When a company has visitors, it is necessary to control the visitor's access behavior while facilitating visitor access. Which of the following authentication methods is generally recommended for this type of visitor scenario?

802.1X authentication

MAC bypass authentication

MAC Authentication

Portal Authentication

6. In the process of deploying WAC on the cloud, the plug-and-play feature of WAC (PnP) can be used to simplify the initial configuration and enable the WAC device to go online quickly.

Which of the following protocols does the WAC use to negotiate with the upstream device (which can be a cloud switch or cloud firewall) to obtain the PnP VLAN as the management VLAN?

LLDP

SNMP

DHCP

NETCONF

7. In a WLAN network, when the AP's transmit power is 100mW, how many dBm is equivalent?

8. How many spatial streams can a 3x2 MIMO system transmit in a WLAN network?

9. Which of the following is not a design principle for indoor AP coverage when planning a WLAN network?

Deploy APs separately in key areas and areas with special needs.

Minimize the number of obstacles that the signal passes through

The AP installation location is more than 3 meters away from the load-bearing column

No need to deploy APs at intersections or corners

10. WLAN Planner supports 3D simulation function. Which of the following simulation modes does 3D building support when performing 3D simulation?

Free walking in walking mode

Automatic walking in walking mode

Walking Mode

Rotation Mode

Page 2 of 20

11. In a WLAN network, when the distance between the AP and the power supply is 300 meters, in order to meet the power supply requirements, in addition to the AP and the switch supporting PoE++ power supply, which of the following cables needs to be used for connection?

Category 6 network cable

Optical-electrical hybrid cable

Category 5e network cable

Category 7 network cable

12. Which of the following descriptions about antenna deployment locations is correct when implementing WLAN outdoor coverage?

It is not recommended to deploy directional antennas at a height higher than 12 meters.

To ensure that there is no blind spot, the antenna should be deployed as low as possible.

To ensure coverage of a larger area, the antenna should be deployed as high as possible

To avoid being blocked by trees, it is recommended that the antenna be deployed at a height of no less than 12 meters

13. In dormitory scenarios, panel APs are generally used and wall-mounted. The figure below shows the network planning scheme for dormitory scenarios. Which of the following schemes is the most reasonable?

Option C

Plan A

Plan D

Plan B

14. An engineer is optimizing the wireless network on a customer's live network. He logs in to the device to check the network status as follows. What problem can be determined by the following command line echo?

The AP channel utilization is too high. It is recommended to perform radio frequency tuning.

The AP's two radio frequencies are unbalanced. It is recommended to enable the spectrum navigation function.

The terminal signal strength is generally low, and there may be coverage issues

The terminal rate is too low. It is recommended to change the AP working protocol to Wi-Fi6.

15. A customer's existing network has a blind spot in wireless signal coverage, resulting in some wired terminals being unable to access the network.

Engineers adjust the transmit power of the surrounding AF to expand the coverage and fill in the blind spots. Which of the following configuration commands for manually adjusting the AR transmit power is correct?

[WAC-wlan] ap-id1 [WAC-wlan-ap-1] radio [WACwlan-radio-1/0] calibrate auto-txpower-select enable [WAC-wlan-radio-1/0] eirp23 [ WAC-wlanradio-1/0 ] radio1 [ WAC-wlan-radio-1/1 ] calibrate auto-txpower-select enable [ WAC-wlan-radio-1/1] eirp 23

[WAC-wlan-ap-group-ap-group1] radio [WACwlan-group-radio-ap-group1/0] calibrate auto-channel-select enable [WAC-wlan-ap-group-ap-group1] radio1 [WAC-wlan-group-radio-ap-group1/1] calibrate auto-channel-select enable WAC-wlan-group-radio-ap-group1/1] quit [WAC-wlan-view] calibrate enable manua [WAC-wlan-view] calibrate manual startup

[WAC-wlan] ap-id 1 [WAC-wlan-ap-1] radio 0 [WAC-wlan-radio-1/0] calibrate auto-txpower-select disable [WAC-wlan-radio-1/0] eirp 23 [WAC-wlan-radio-1/0] radio 1 [WAC-wlan-radio-1/1] calibrate auto-txpower-select disable [WAC-wlan-radio.1/1jeirp 23

[WAC-wlan-ap-group-ap-group1] radio 0 [WAC-wlan-group-radio-ap-group1/0] calibrate auto txpower-select enable [WAC-wlan-ap-group-ap-group1] radio [WAC-wlan-group-radio-ap-group1/1] calibrate auto-txpower-select enable [WAC-wlan-group-radio-ap-group1/1] quit [WAC - wlan-view] calibrate enable manual [ W AC-wlan-view ] calibrate manual startup

16. In the RF tuning solution, which of the following descriptions about the dynamic frequency band adjustment function is wrong?

When the redundant radio is switched to 5G, its channel is the default 5G channel.

During the dynamic frequency band adjustment process, once the vulnerability detection mechanism detects that the 2.4G radio has a coverage vulnerability, the switched 5G radio will switch back to the 2.4G radio.

Mainly for automatic identification and adjustment of Yuanyu 2.4G radio frequency

If the dynamic frequency band adjustment function is turned off, the remaining radios will maintain the current working mode

17. Which of the following steps does not belong to the "five-step network planning" of WLAN Planner?

Environment Setup

Import drawings

Regional Settings

Export Report

18. When using CloudCampus APP for project delivery, which of the following tools does not include the one that users need to log in to the WLAM Planner project with their account?

Delivery

Acceptance

AP Calculator

Site Survey

19. When a large enterprise deploys a wireless network, it needs to provide wireless access services for both internal employees and temporary visitors. Visitor traffic may bring potential security threats to the network. In order to ensure the security of the enterprise network, which of the following networking methods is recommended?

NaviAc Networking

WAC+FITAP networking

Agile distributed networking

Networking with onboard AC

20. Which of the following descriptions about the AC networking mode included with the board is wrong?

The onboard AC networking can realize the unified management of wired and wireless networks and improve the efficiency of network operation and maintenance

The AC can be deployed in the aggregation layer or the core layer of the network and is suitable for WLAN networks in medium and large campuses.

Compared with independent WAC networking, on-board AC networking supports more WLAN functions and features.

Compared with independent WAC networking, on-board AC networking can effectively reduce network construction costs.

Page 3 of 20

21. As shown in the figure, a company's WLAN network uses N+1 backup networking. Which of the following descriptions about N+1 backup is wrong?

You can configure the AP's individual priority on the primary and backup WACs. The larger the priority value, the higher the priority.

All APs under the main WAC1 and main WAC2 must be configured on the backup WAC3 to ensure that the APs can obtain the correct configuration after the WAC is switched.

The backup WAC3 and the primary WAC1 and WAC2 can be deployed in different locations to ensure intercommunication between the three-layer networks.

You can configure the corresponding MAC whitelist on the primary WAC to ensure that the AP can go online on the corresponding WAC to assist the AP in selecting the correct primary WA

22. Which of the following data encryption algorithms is used in the WEP security policy?

3DES

AES

RC4

DES

23. In WPA/WPA2 encryption, which of the following keys can be used to encrypt multicast and broadcast wireless messages?

Group Master Key

Pairwise Transient Key

Group Temporal Key

Pairwise Master Key

24. In a WLAN network environment, wireless client access can be controlled through blacklist and whitelist policies. Which of the following statements about blacklist and whitelist is wrong?

Enable the whitelist function. If the whitelist is not empty, only STAs matching the whitelist can go online, and other STAs cannot go online.

Enable the blacklist function. If the blacklist is empty, any STA is allowed to go online.

Enable the blacklist function. If the blacklist is not empty, STAs matching the blacklist cannot go online, but other STAs can go online.

Enable the whitelist function. If the whitelist is empty, no STA is allowed to go online.

25. In existing network applications, there is a type of terminal that has poor roaming initiative, which is mainly manifested in that it always "sticks" to the AP it initially associated with. Even if the terminal moves far away from the currently associated AP, the signal is weak, and the rate is low, this type of terminal still cannot roam to other neighboring APs with better signals.

This type of terminal is called a sticky terminal. Which of the following is a roaming optimization solution for sticky users?

802.11r fast roaming

Layer 3 roaming

PMK Fast Roaming

Smart Roaming

26. An engineer inspected the customer's live network and found that the VRPP hot backup failed to be established. He queried relevant information through the following command line, and the following information was displayed.

According to the echo information, which of the following is the main reason for the failure of hot standby establishment?

The VRRP status is abnormal. It is recommended to check the VRRP configuration.

The HSB link is not configured. It is recommended to check the HSB configuration module.

HSB function is not enabled. It is recommended to enable HSB function.

The HSB channel is not connected. It is recommended to check the HSB network connectivity between the active and standby ACs.

27. The Airtime scheduling function is mainly used to schedule the wireless channel occupation time of each user to ensure that each user occupies the wireless channel relatively fairly.

As shown in the figure below, there are four users User1, User2, Uuser3 and USser4 in the transmission queue, and the four users currently occupy the channel for 5, 4, 6 and 7 times respectively.

When the Airtime scheduling function is turned on, which user will be prioritized next?

User3

User2

User4

User1

28. Engineers are deploying Huawei's cloud management solution at the customer site. All APs in the existing network are managed by the cloud platform.

During the project implementation, the engineer logged in to the cloud AP and queried the online status through the following command line. The following is the response.

Which of the following descriptions of the command line output is wrong?

The cloud AP has been successfully launched on the cloud platform

The IP address of the cloud platform is 10.1.1.1

The port number of the cloud platform is 10020

Cloud AP obtains the cloud platform address through DHCP parameters

29. A terminal communicates with an AP using the Wi-Fi 6 protocol. If the communication bandwidth is 80 MHz and the number of spatial streams is 2, what is the maximum theoretical rate between the terminal and the AP?

2400 Mbps

600 Mbps

1800Mbps

1200 Mbps

30. Which of the following authentication methods is generally used for newly built networks, concentrated users, and strict information security requirements?

MAC Authentication

1X Authentication

MAC-first Portal authentication

Portal Authentication

Page 4 of 20

31. In wireless access control scenarios, which of the following methods is most recommended for distinguishing between internal employees and external visitors?

Differentiate by different user names

Set up different SSIDs for employees and guests

Differentiate by type of wireless terminal

Differentiate based on whether the wireless terminal MAC address is registered

32. To improve user experience, engineers configure the roaming function on the wireless controller and specify that the smart roaming function is triggered by detecting the terminal rate. Which of the following configuration commands is correct?

[WAC-wlan-view] rrm-profile name smart-roam [ WAC-wlan-rrm-prof -smart-roam] smart-roam enable [WAC-wlan-rrm-prof-smart-roam] smart-roam roam-threshold check-rate

WAC-wlan-view] vap-profile name smart-roam [WAC-wlan-vap-prof-smart-roam] smart-roam enable [WAC-wlan-vap-prof-smart-roam] smart-roam roam-threshold check- rate

WAC-wlan-view] vap-profile name smart-roam [WAC-wlan-vap-prof-smart-roam] undo smart-roam disable [WAC-wlan-vap-prof-smart-roam] smart-roam roam-threshold check-snr

WAC-wlan-view] rrm- profile name smart -roam [WAC-wlan-rrm-prof-smart-roam] smart-roam enable [WAC-wlan-rrm-prof-smart-roam] smart-roam roam-threshold check-snr

33. Which of the following descriptions of RF tuning solutions is wrong?

For radios configured with WDS bridges or Mesh links, the radio tuning A function does not take effect.

Global tuning is performed on all APs

If the RF channel switch is triggered during the scanning process, the user service data delay will increase at the moment of channel switching, which may affect the wireless service experience

The RF tuning function is suitable for high-density scenarios and outdoor directional antenna coverage scenarios

34. In WLAN networks, the 24 GHz frequency band is divided into 14 overlapping channels with a frequency width of 20 MHz (except 802.11b). Which of the following channels is a commonly used non-overlapping channel in existing networks?

1, 4, 7 and 13

1, 7, 9 and 13

1, 5, 9 and 13

1, 3, 5 and 9

35. The figure below shows a schematic diagram of the library scenario network planning solution. Which of the following descriptions of the solution is correct?

The bookshelf area is recommended to be installed on the ceiling according to Plan 1, and the study area is recommended to be installed on the ceiling according to Plan 1

It is recommended to install the bookshelf area according to plan 1 and the study area according to plan 2.

It is recommended to install the bookshelf area according to Plan 2 and the study area according to Plan 1.

The bookshelf area is recommended to be installed on the ceiling according to Plan 2, and the study area is recommended to be installed on the ceiling according to Plan 2

36. Which of the following items is not included in the Wi-Fi experience test conducted through the CloudCampus app?

Terminal link establishment rate test

Internet Performance Testing

Web connectivity test

Ping packet test

37. Which of the following descriptions about AP antenna installation methods is wrong?

The main lobe direction of the directional antenna should be facing the target area

The omnidirectional outdoor antenna cannot be placed randomly, but must be installed vertically to ensure that the beam direction evenly covers the designated area.

The closer the distance between the 4G antenna and the 5G antenna, the better

The antenna installation location should avoid being blocked by building beams and metal to reduce attenuation losses caused by obstacles.

38. Campusinsight wireless health refers to the comprehensive experience evaluation of a wireless network terminal, and the wireless health report can be generated and sent to customers.

Which of the following descriptions about wireless health reports is wrong?

Wireless health reports can be sent to customers via email or WeChat

After selecting the start and end time as the wireless health report data analysis period, you can choose to directly download the wireless health report

Wireless health reports currently support sending by day, week, biweekly, month, etc.

If you enable the scheduled sending of wireless health reports, you need to select a user group and send the report to the corresponding user group members.

39. When an engineer was debugging a wireless network at a customer site, the radio frequency tuning function configured on the device did not take effect. The engineer checked the current radio frequency tuning status on the wireless controller, and the following was displayed.

After analyzing the displayed information, which of the following may be the cause of the failure of radio frequency calibration?

No VAP template is configured on the device

The channel and power automatic selection functions are disabled on the device.

AP did not detect neighbor information

Device tuning is not completed

40. Which of the following is the default management SSID name when the AP is in FITAP or Cloud AP mode?

HUAWEI-LeaderAP-xxxx, where xxxx is the last four digits of the AP MAC address

xxxx is the unsigned 4-digit AP MAC address.

HUAWE lmanage xxxx, where xxxx is the last four digits of the AP MAC address

HUAWE xxxx xxxx is the last four digits of the AP MAC address

Page 5 of 20

41. As shown in the figure, in the N+1 backup networking scenario, WAC3 is configured with a global priority of 5, and WAC1 and WAC2 are configured with a global priority of 6 Configure AP1's personality priority as 3 on WAC1, and AP3's personality priority as 3 on WAC2. If WAC1, WAC2, and WAC3 are all unloaded, which WAC device will AP1, AP2, AP3, and AP4 connect to?

AP1 accesses WAC2, AP2 accesses WAC1 or WAC2, AP3 accesses WAC1, AP4 accesses WAC1 or WAC2

AP1 accesses WAC2, AP2 accesses WAC3, AP3 accesses WAC1, and AP4 accesses WAC3

AP1 accesses WAC1, AP2 accesses WAC3, AP3 accesses WAC2, and AP4 accesses WAC3

AP1 accesses WAC1, AP2 accesses WAC1 or WAC2, AP3 accesses WAC2, and AP4 accesses WAC1 or WAC2

42. As shown in the figure, in the dual-link load-sharing hot standby network, AP1 is a newly launched AP, and both WACs have the configuration to access this AP. Which of the following WACs will AP1 access first?

WAC1

No access

WAC2

Random Access

43. During the STA access process, a link authentication phase is required. During this phase, which of the following security policies supports the shared key authentication mechanism?

WAPI

WFA3

WEP

WPA2

44. The engineer deployed a wireless environment in the customer's existing network. After completing the AP online and service configuration on the wireless controller, he used the terminal to associate the signal and found that the corresponding SSID could not be searched.

Which of the following is NOT the cause of this problem?

AP power supply is insufficient

The AP's radio frequencies are all turned off

The test terminal does not support the currently configured country code

The AP's working channel is a radar channel and needs to be silent for a period of time

45. When using WLAN Planner to automatically identify obstacles, which of the following types of drawings does not support the "automatic identification" function as shown in the figure?

PDF

JPG

PNG

CAD

46. Which of the following tools can be used by users to obtain project information from WLAN Planner through the CloudCampus APP on their mobile phones and view AP location and heat map information on the APP at any time?

Network regulations

Acceptance

AP Calculator

Site Survey

47. In the outdoor backhaul scenario, which of the following descriptions of the site selection principle is wrong?

If there is other Wi-Fi interference near the site, you can set it to a different channel or coordinate to turn off the interference source.

The site should be selected away from strong electric and magnetic fields

The site should be located in an open area with no obstacles nearby.

If there are obstacles near the site, the height of the pole only needs to be higher than the obstacle.

48. The terminal dial test report mainly includes three parts: an overview of the evaluation results, an overview of the manufacturer's indicators, and test details. The overview of the manufacturer's indicators mainly displays and analyzes the test results of each test item.

Which of the following descriptions of the manufacturer's indicator overview in the test report is wrong?

Manufacturer Index Overview In addition to providing the test results of each test item, it also provides evaluation interpretation and problem location

When the terminal signal strength is greater than or equal to -65dBm, the indicator evaluation result is excellent

When the Ping packet delay is less than or equal to 10ms, the indicator evaluation result is excellent

When the file download rate is greater than or equal to 25 MBps, the indicator evaluation result is excellent

49. The overall architecture of Huawei's terminal dial-up test solution is shown in the figure below, where CampusInsight is the background analysis tool.

Which of the following descriptions about CampusInsight is wrong?

Implement the data receiving backend server capability and be responsible for receiving and parsing the data reported by the APP

Provide ratings and improvement reports

Summarize and display the dial test data on the platform

Link with the device and adjust the device parameter configuration according to the dial test report

50. A customer's existing network has many old terminals, and the roaming sensitivity is high. The signal strength is already very low, but the terminal does not start roaming, resulting in a poor terminal experience. The customer requires that the terminal can switch to other APs when the signal strength is lower than -75 dBm, so the weak signal user offline control function is enabled on the wireless controller.

Which of the following configuration commands for controlling the offline of weak signal users is correct?

[WAC-wlan-view] rrm-profile name test [WAC-wlan - rrm-prof-test] smart-roam quick-kickoff-Threshold enable [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-threshold check-snr [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-threshold snr 75

[WAC-wlan-view] rrm-profile name test [WAC-wlan-rrm-prof-test] undo smart-roam quick-kickoff-threshold disable [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-threshold check-snr [WAC-wlan-rm-prof-test] smart-roam quick-kickoff-threshold snr 75

WAC-wlan-view] rrm-profile name test [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-Threshold enable [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-threshold check-snr [WAC-wlan-rrm-prof - test] smart-roam quick-kickoff-threshold snr 20

WAC-wlan-view] rrm-profile name test [WAC-wlan-rm-prof-test] undo smart-roam quick-kickoff - threshold disable [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-threshold check-snr [WAC-wlan-rrm-prof-test] smart-roam quick-kickoff-thresholds nr 20

Page 6 of 20

51. Huawei's CampusInsight intelligent operation and maintenance platform includes dashboard problem analysis, network experience and other operation interfaces. The CampusInsight interface shown in the figure is which of the following operation interfaces?

Experience Analysis Interface

WLAN device interface

Wireless Health Interface

Telemetry interface

52. The engineer logged into CampuslInsight to inspect the customer's wireless network. By checking the wireless problem analysis (the results are shown in the figure below), it was found that one of the A devices had a non-5 priority access problem.

Which of the following could not be the cause of this problem?

5G power is too low

5G priority function is turned off

Too many access terminals

There is an obstacle blocking the signal

53. When an engineer was debugging a wireless network at a customer site, the RF tuning function configured on the device did not take effect. The engineer initially suspected that the AP was unable to detect neighbor information.

Which of the following command lines can an engineer enter on the wireless console to view AP neighbor information?

<WAC>display ap 11dp neighbor

<WAC>display pim neighbor

<WAC>display neighbor all

<WAC>display ap neighbor

54. In the Portal authentication scenario, the wireless controller is used as the access device and the Portal protocol is used to communicate with the Portal server. Which of the following descriptions of the Portal protocol is wrong?

By default, the access device listens on port 2000.

By default, the destination port number used by the device to actively send messages to the Porta1 server is 50100

HTTP/HTTPS protocol can be used as Portal access protocol or Portal authentication protocol

Portal protocol is based on TCP protocol for data transmission

55. An engineer configures the smart roaming policy as follows. Which of the following configuration descriptions is wrong?

If the terminal rate is less than 30% of the maximum rate, the smart roaming conditions are met.

If the terminal signal-to-noise ratio is higher than 25B, then the smart roaming conditions are met.

The high difference threshold for triggering STA roaming guidance is 16dB, and the low difference threshold is 8dB

Smart roaming is triggered by detecting the terminal SNR and the terminal rate.

56. Which of the following descriptions about 802.11r fast roaming is wrong?

According to the protocol standard definition, 802.11r fast roaming includes Over-the Air and Over-the-DS

802.11r fast roaming requires the terminal to support the 802.11r protocol

802.11r fast roaming is applicable to security policies such as WPA2-PSK-AES, WPA2-PPSK-AES, and WPA2-802.1×-AES

802.11r fast roaming omits the key negotiation process through pairwise master key caching technology, thereby reducing roaming delay

57. Which of the following descriptions about static load balancing is wrong?

Each load balancing group has a maximum of 16 AP members.

If it is a multi-band AP, load balancing can be achieved between radios in different frequency bands.

For agile distributed networking such as central AP+RU, you only need to add the RU's radio to the static load balancing group.

Add some APs that provide the same service to a load balancing group through manual configuration

58. The wireless terminal migration function can migrate terminals with poor service experience to suitable APs based on the actual WLAN network environment. Terminal migration methods include BTM or deauth.

When the terminal supports which of the following protocols, the AP preferentially uses the BTM method to migrate the terminal?

802.11r

802.11i

802.11k

802.11v

59. When planning the network in a sports stadium, there are three main ways to install APs: side installation, ceiling installation, and under-seat installation.

Which of the following descriptions of the three installation methods is correct?

When installing under the seat, it is necessary to destroy the existing building surface and add steel pipes for wiring, which is less aesthetically pleasing.

When installing the ceiling, the construction cost is higher for the ceiling with simple structure and high height, but the anti-interference performance is better than the side cover.

When installed on the side, the device is installed at a lower position and there is a risk of being touched by the audience, but the appearance is good.

The transmission between the terminal and AP in the three installation methods is line-of-sight, and the loss is controllable.

60. An engineer is optimizing the customer's existing network and finds that the terminal rate is generally low and the experience is not good. Check the working channel of the AP on the device and find that the working channels of all APs are the same.

In view of the above phenomenon, which of the following methods can engineers use to optimize the network?

Enable weak signal user access control

Enable offline control for users with weak signals

Enable automatic RF tuning

Enable load balancing

Page 7 of 20

61. To prevent non-critical services from occupying too much network resources, QoS policies can be configured in application protocols, namely smart application control SAC.

Which of the following descriptions of SAC functions is wrong?

SAC mainly detects and identifies the 4th to 7th layer content and some dynamic protocols (such as HTTP, RTP) in the message, and implements refined QoS policy control based on the classification results

For the identified application protocol packets, their priority can be modified or directly discarded

In roaming scenarios, the SAC policy of the user after roaming is based on the policy issued by the device accessed after roaming.

When a CAPWAP tunnel is established between WAC and AP to centrally forward user messages, the SAC service will be deployed on the A

62. Engineers can export a wireless health report from the CampusInsight platform to analyze the status of the entire wireless network. The health report evaluates each quality indicator. Which of the following quality indicators is not included in the report?

Roaming compliance rate

Access success rate

Device CPU utilization

Access time

63. Multicast messages are sent at a low rate on the air interface. A large number of such messages will occupy a large amount of air interface resources, affecting the transmission of normal user service data packets. In scenarios without multicast services, when the service data forwarding method adopts tunnel forwarding, it is recommended to configure multicast message suppression on WAC.

Which of the following configuration commands for the multicast packet suppression function is correct?

[WAC-wlan-view] rrm-profile name test [WAC - wlan-rm-prof-test] traffic-optimize multicast-suppression packets 1000

WAC-wlan-view] traffic-profile name test [WAC-wlan-traffic-prof-test] traffic-optimize broadcast-suppression packets 1000

[WAC-wlan-view] traffic-profile name test [WAC-wlan-traffic-prof-test] traffic-optimize multicast-suppression packets 1000

WAC-wlan-view] rrm-profile name test [WAC - wlan-rrm-prof-test] traffic-optimize broadcast-suppression packets 1000

64. During the wireless network optimization process, which of the following tools can be used to assist in optimization in order to understand information such as wireless signal interference, wireless signal strength, and terminal performance in the network?

Terminal dialing tool

Antenna Alignment

iPerf

CloudCampus APP

65. As shown in the figure, this is the customer's demand for a conference room. Based on these parameters, how many APs are needed to meet the capacity requirements of the conference room?

66. When planning the network for the stadium stand area, which of the following scenarios is suitable for deploying APs using a combination of edge and ceiling coverage?

The maximum number of seats in a single-tier stand is no more than 20 rows

The maximum number of seats in a single-tier stand is no more than 30 rows

Scenario with more than 30 rows of seats in a single-tier stand

The maximum number of seats in a single-tier stand is no more than 25 rows

67. Which of the following tools can be synchronized with WLAN Planner to view network planning results on a mobile phone?

eDeskA

CloudCampus APP

WLAN Tester 2.0

Antenna Alignment

68. RF tuning is a RF resource management solution that enables wireless networks to quickly adapt to changes in the wireless environment. Which of the following does the RF tuning process not include?

Channel Adjustment

Neighbor Detection

Load Balancing

Power adjustment

69. Which of the following protocols defines the standards and specifications of Mesh technology?

802.11s

802.11i

802.11r

802.11e

70. In an N+1 backup scenario, the switchover between the primary and backup WACs is determined by the AP. By default, if the AP does not receive a CAPWAP heartbeat detection message from the primary WAC within how many seconds, the primary and backup switchover will be triggered?

180

150

Page 8 of 20

71. By default, how many users can LeaderAP support to log in through the Web management method at the same time?

72. In a Portal authentication scenario, which of the following devices cannot be used as a Portal authentication server?

Switch

iMaster NCE-Campus

WAC

General purpose web server

73. Roaming switching time is a core indicator that affects the service experience of wireless users during roaming. PMK fast roaming can shorten the roaming delay of 802.1x users and improve the user's Internet experience.

So PMK roaming reduces the user's roaming delay in which of the following ways?

Omitting the key negotiation process

Omitting the 802.1X authentication process

The user re-association process is omitted

Omitted the 802.1X authentication process and key negotiation process

74. When an engineer is optimizing the network, in order to prevent non-critical services from occupying too much network resources, he configures the QoS function based on the application protocol. The specific configuration is as follows.

Which of the following descriptions of configuration is wrong?

All apps in the specified app list discard FaceTime messages

SkypeForBusiness's DSCP priority is 40

You can view user-based protocol statistics

You can view protocol statistics based on VAP

75. In the WLAN networking shown in the figure, STA roams between WACs. The data forwarding mode of the two WACs in the figure is tunnel forwarding. The gateways of the service VLAN are both located on the core switch Switch1.

The home agent uses the default configuration. Which of the following descriptions of the data forwarding path after roaming is correct? A. STA->AP2->WAC2->WAC1->Switch1->AR1>Internet

B. STA->AP2->WAC2->Switch1->AR1->Internet

C. STA->AP2->WAC2->WAC1->AP1->Switch1->AR1->Internet

D. STA->AP2->WAC2->WAC1->AP1->WAC1->Switch1->AR1->Internet

76. In a WLAN network, which of the following typical obstacles has the correct order of signal attenuation values from small to large?

Ordinary glass window <12 cm brick wall <metal wall <24 cm brick wall

12cm brick wall < 24cm brick wall < metal wall < ordinary glass window

12cm brick wall < 24cm brick wall < ordinary glass window < metal wall

Ordinary glass window <12 cm brick wall <24 cm brick wall <metal wall

77. An engineer is optimizing the wireless network. In order to prevent non-critical services from occupying too much network resources, he turns on the QoS function based on the application protocol. The current network has completed the wireless network deployment, and the data forwarding method of wireless users is tunnel forwarding. Then, on which of the following devices should the QoS function based on the application protocol be deployed?

AP directly connected to the upper switch

User gateway equipment

WAC

78. When the engineer checked the AP status through the Huawei wireless controller web interface, he found that the AP status was displayed as config.

Which of the following options is correct about this status?

WLAN service configuration delivery failure during AP online process

WLAN service configuration is being delivered after AP goes online

The WLAN service configuration is being delivered during AP online process

WLAN service configuration fails to be delivered after AP goes online

79. An engineer configures the spectrum navigation function on a wireless controller. The command line is as follows. Which of the following descriptions of the configuration command is wrong?

[WAC-wlan-view] r rm-profile name wlan rrm

[WAC-wlan-rrm-prof-wlan- r rm] band-steer balance start-threshold 20

[WAC-wlan-rrm-prof-wlan-rrm] band-steer balance gap-threshold 60

[WAC-wlan-rrm-prof-wlan-r r m] band-steer snr-threshold 20

[WAC-wlan-rrm-prof-wlan-rrm] band - steer deny-threshold 6

[WAC-wlan-rrm-prof-wlan - rrm] quit

When the SNR in the 5G Probe sent by the terminal to the AP exceeds 20 dB, 5G access is given priority.

When the number of users connected to the AP does not reach 20, new terminals will be given priority to access 5G

When the number of users connected to the AP does not reach 20, the new online terminal initiates an association request using 2.4G, and the AP will reject its association. The maximum number of rejections is 6 times

When the number of users accessing the AP exceeds 20, the proportion of 5G RF access users will be calculated. If it exceeds 60%, the newly launched terminals will be guided to access 5G first.

80. In a WLAN network, which of the following configuration commands can change the GI mode of the AP2.4GHz radio to 1.6 microseconds?

[WAC-wlan-radio-2g-prof-default] guard - interval-mode norma

[WAC-wlan-radio-2g-prof-default] guard-interval-mode dotllax 1dot6

[WAC-wlan-radio-2g-prof-default] guard-interval-mode short

[WAC-wlan-radio-2g-prof-default] guard-interval-mode dotllax 3dot2

Page 9 of 20

81. In the medical infusion hall scenario, the indoor floor height is 35 meters, the user distribution is 2 square meters per person, and the business types include web browsing, games, videos, and instant messaging.

Which of the following network deployment suggestions for this scenario is wrong?

It is recommended to deploy APs at equal intervals of 15 to 18 meters

Install the AP away from interference sources

It is recommended to use indoor directional AP and wall mount it.

It is recommended to install the AP at least 3 meters away from the load-bearing column.

82. An engineer logs in to the wireless controller web interface to check the AP status. The AP status queried is shown in the figure below. Which of the following descriptions of the AP status in the figure is correct?

Initial state before AP and WAC establish link

AP unauthenticated state

AP type mismatch status

AP is in the upgrading state

83. The engineer inspected the customer's wireless network and found that the service experience was not good using the terminal. The engineer checked the terminal service experience through the user journey function of CampusInsight.

The user journey is shown in the figure below. Which of the following may be the cause of this poor user experience?

The terminal itself has poor performance, resulting in a low negotiation rate

Low terminal signal strength leads to poor experience

The terminal does not support the 802.11r protocol and cannot perform 802.11r roaming, resulting in poor roaming performance

The terminal enters power saving mode, resulting in packet loss

84. The customer's existing network has configured inter-WAC roaming. The engineer checked the information of the roaming group on the wireless controller and found the following description of the roaming group. Which one is wrong?

The terminal can roam normally between the WACs in the above roaming groups.

The current link of WAC with IP address 192.168.10.1 is normal

There are three WACs in this roaming group.

The current link of the WAC with IP address 192.168.10.3 is disconnected

85. The current Wi-Fi 6 protocol modulation method already supports 1024 QAM. Compared with 256-QAM, how much is the physical layer link establishment rate increased by 1024-QAM?

0.5

0.25

0.2

86. In a WLAN network, how many spatial streams can a single radio support at most according to the 802.11ac and 802.11ax protocols?

87. In the WLAN network planning project, after using WLAN Planner to import CAD drawings, which of the following steps needs to be performed to generate the corresponding floors?

It depends on the size of the CAD drawing. If the drawing is too large, it needs to be cut and submitted.

Submit CAD drawings directly

Import the drawing and select the area before submitting

After importing, no additional operations are required to use

88. Which of the following descriptions of the spectrum analysis function of Campusnsight is wrong?

CampusInsight spectrum analysis is based on the full channel status monitoring capability of the A

If the wireless device does not have the channel scanning function enabled, this function cannot be realized.

CampusInsight presents real-time full-channel status monitoring based on AP granularity and supports viewing historical trend graphs

To ensure that the spectrum analysis function of CampusInsight is displayed normally, the spectrum analysis function needs to be enabled on the wireless controller in advance.

View the device spectrum analysis details on the platform, including device information, full channel status monitoring, non-Wi-Fi interference sources, Wi-Fi interference sources, and illegal devices.

89. In WLAN network, there are four transmission systems: SISO, MISO, SIMO and MIMO. Which of the four transmission systems can transmit two signals at the same time?

SIMO

SIso

MISO

MIMO

90. In WLAN networks, how many microseconds is the GI fixed in the 802.11a/b/g standard?

3.2

0.4

0.8

1.6

Page 10 of 20

91. In WLAN network, according to different channel bundling methods, the channel working bandwidth can be divided into several different types: 40MHz+, 40 MHz, 80 MHz, 80+80 MHZ and 160MHz.

Which of the following descriptions about the operating bandwidth of an 80MHz channel is correct?

80MHz is to bundle two consecutive 40MHZ channels together and select the higher frequency among the four 20MHz channels as the main channel

80MHz is to bundle two consecutive 40MHZ channels together and select one of the four 20MHz channels as the main channel

80MHz is to bundle two discontinuous 40MHZ channels together and select the higher frequency among the four 20MHZ channels as the main channel

80MHz is to bundle two discontinuous 40MHZ channels together and select one of the four 20MHz channels as the main channel

92. In network capacity design, which of the following is not a consideration for capacity setting?

Access concurrency rate

User bandwidth requirements

Number of access users

AP point

93. In a WLAN network, which of the following protocols cannot work in the 2.4 GHz frequency band?

802.11ac

802.11g

802.11ax

802.11n

94. In the network planning process, user concurrency rate is one of the important parameters for network capacity design. Which of the following descriptions about user concurrency rate is correct?

User concurrency rate refers to the ratio of the number of high-traffic service terminals to the number of service-generating terminals in a scenario.

User concurrency rate refers to the ratio of the number of terminals generating services in the scene to the total number of terminals.

User concurrency rate refers to the ratio of the number of terminals generating services in the scene to the number of terminals accessing the network.

User concurrency rate refers to the ratio of the number of terminals connected to the network in the scene to the total number of terminals.

95. An engineer logs in to WAC to check the terminal roaming track and finds the roaming track as shown below. Which of the following descriptions of the terminal roaming situation is wrong?

The signal strength is -58dBm when the terminal accesses a new AP after roaming

The terminal roams from AP: test1 to AP: test2

The name of the wireless signal accessed by the terminal is test

The terminal experienced an 802.11r roaming

96. The wireless air interface is a virtual logical interface on an AP or terminal. Many factors affect the performance of the wireless air interface, but which of the following factors is not included?

Interference from non-WLAN devices

Differences in terminal capabilities

Switch forwarding capability

Interference from WLAN equipment

97. In WLAN network, which of the following descriptions about Symbol and GI is wrong?

The role of GI is to reduce the interference between symbols

Symbol's unit is microseconds, which indicates the time required to transmit the modulated data of each channel together.

GI is in microseconds, indicating a protection interval

The larger the GI, the higher the transmission efficiency

98. Which of the following descriptions about Huawei CloudCampus APP is wrong?

You can view the signal interference of the current network through the CloudCampus APP, such as signal name, working channel, signal strength, etc.

CloudCampus APP is a mobile APP that integrates functions such as field strength detection and interference testing.

You can view the current Wi-Fi status information, such as signal strength, channel, negotiated rate, etc. through the CloudCampus APP

You can view the MAC address of the AP associated with the current terminal through the CloudCampus APP

99. The overall signal coverage of the wireless network deployed by a customer is good, but the signal at the edge of the coverage is weak. In order to avoid weak signal access of terminals and affect the experience, the customer requires that terminals are not allowed to access the network when the signal strength is lower than -75dBn, so the weak signal user access control function is enabled on the wireless controller.

Which of the following configuration commands regarding weak signal terminal access control is correct?

[WAC-wlan-view] rrm-profile name test [WAC-wlan-rm-prof-test] uac client-snr enable [WAC-wlan-rrm-prof-test] uac client-snrthreshold 75

[WAC-wlan-view] rrm-profile name test [WAC-wlan-rrm-prof-test] uac client-snr enable [WAC-wlan-rrm-prof-test] uac client-snrthreshold 20

[WAC-wlan-view] rm-profile name test [WAC-wlan-rrm-prof-test] undo uac client-snrdisable [WAC-wlan-rrm-prof-test] uac client-snrthreshold 20

[WAC-wlan-view] rrm-profile name test [WAC-wlan-rrm-prof-test] undo uac client-snrdisable [WAC-wlan-rrm-prof-test] uac client-snrthreshold 75

100. In the stadium hall scene, the floor heights mainly include ordinary areas (3 meters) and high-ceiling areas (greater than 6 meters).

Which of the following descriptions of the network planning solutions for these two areas is wrong?

Both areas can be covered by omnidirectional APs

When deploying APs in both areas, they should be as far away from the stadium seating area as possible.

If the floor height is between 3 and 6 meters, it is recommended to place APs on the ceiling at a spacing of 18 to 25 meters.

For areas with a floor height of more than 6 meters, it is recommended that APs be wall-mounted, deployed at intervals of 18 to 25 meters, and at least 3 meters away from load-bearing columns.

Page 11 of 20

101. A customer deployed Huawei's traditional wireless solution on site, with WAC managing the APs. After the engineer completed the network deployment, the user reported that the terminal roaming failed and the experience was not good.

Which of the following is not likely to be the cause of the terminal roaming failure?

The AP security profile configuration is inconsistent before and after roaming

AP signal coverage is discontinuous and there are blind spots

The user is roaming at Layer 3, but the device prohibits Layer 3 roaming

The AP data forwarding mode is different before and after roaming

102. A large enterprise needs to deploy a VLAN network in the office environment to provide employees with services such as wireless Internet access, wireless office and wireless roaming.

The enterprise hopes to control costs as much as possible while meeting the needs and taking into account the unified management of wired and wireless networks. Which of the following networking methods is the best?

Cloud TAC Networking

VAC+FITAP networking

Networking with onboard AC

Leader AP Network

103. In the VAC+FITAP networking mode, which of the following descriptions about Layer 2 and Layer 3 networking is wrong?

Both Layer 2 and Layer 3 networks support VAC side-by-side deployment. The difference between the two is that the service data in Layer 2 networking does not need to be forwarded by VA

In a three-layer network, VAC and FITAP communicate through a three-layer network, and FITAP can discover VAC through DHC

Both Layer 2 and Layer 3 networking support VAC direct connection deployment, and the business data of both needs to be forwarded by VAC

In Layer 2 networking, VAC and FITAP are located in the same Layer 2 network. FITAP can discover TAC through broadcasting.

104. Under the premise of the same material thickness, which of the following obstacles has the greatest attenuation for 5GHz signals?

Asbestos

Colored thick glass

Synthetic Materials

Wooden door

105. As shown in the figure, which of the following descriptions of the CampusInsight interface is correct?

Engineers are checking the service topology

Engineers checking performance experience

Engineer looking at the wireless user journey

Engineers are checking the health of wireless users

106. A wireless network is deployed in an office area. During the experience period, customers reported that the Internet speed was slow. Which of the following cannot be the cause of this problem?

AP5G radio frequency is turned off A

qos car speed limit is configured in the SSID template on the wireless controller

User access uses WPA2-PSK authentication

Severe air interface interference

107. By default, when LeaderAP manages other FITAPs, which of the following authentication methods is used?

No certification

Pre-shared password authentication

MAC Authentication

SN certification

108. In the wireless coverage scenarios of wards and clinics, engineers proposed two network planning solutions as shown in the figure.

Which of the following descriptions of these two solutions are correct?

If the walls between rooms are brick walls, it is recommended to use solution A, which is to place a panel AP or RU in each room and mount it on the wall.

If the walls between rooms are brick walls, it is recommended to use solution A, which is to place a panel AP or RU in each room and install it on the ceiling.

If the wall between the rooms is a gypsum wall, it is recommended to use solution B, one AP or RU covers two rooms and is mounted on the wall.

If the walls between the rooms are plaster walls, it is recommended to use solution B, where one AP or RU covers two rooms and is installed on the ceiling.

109. In WLAN networks, which of the following GI intervals does not belong to the 802.11ax standard?

1.6 microseconds

0.8 microseconds

3.2 microseconds

0.4 microseconds

110. When configuring WLAN services, you can configure the service VLAN as a VLAN pool . Which of the following descriptions about VLAN Pool is wrong?

The allocation algorithm of the VLAN pool is hash. If the same STA goes online multiple times, the previously used address will be given priority.

The created VLAN cannot be added to the VLAN pool

Configuring a VLAN pool can effectively reduce the number of STAs in a single VLAN and reduce the broadcast domain.

If the VLAN pool allocation algorithm is even, the same STA goes online multiple times, and the address obtained each time is usually different.

Page 12 of 20

111. After a customer completed the wireless network deployment on the existing network, all APs worked on the same channel, causing serious interference. Automatic radio frequency adjustment was enabled on the wireless controller, and the current tuning progress was checked through the command line. The following is the result.

So which option is wrong in the description of the following command line echo?

The sensitivity of RF tuning is medium

2.4G tuned channel set is 1.6, 11

The current tuning has ended

The configured tuning mode is manual mode

112. In Huawei Cloud Management Solution, Cloud AP has multiple ways to obtain the cloud platform address. Which of the following is not included?

Obtained through DHCP

Obtain through the registration center

Obtained through WAC

Manually configure on the cloud AP through the command line

113. In the CloudCampus APP, which of the following tools can be used to perform "attenuation testing" on site?

AP Calculator

Network Regulation

Site Survey

Acceptance

114. Which of the following descriptions about the roaming experience test function in the CloudCampus app is wrong?

During the test, the terminal needs to associate with the wireless signal and walk in the network coverage area to complete the roaming test.

After the roaming test is completed, the roaming test report will be automatically sent to the customer via email

Ping packets continuously during the test and evaluate the roaming effect by observing packet loss during the roaming process

You can customize the Ping packet address during the roaming test

115. When deploying Portal authentication on a Huawei wireless controller using iMaster NCE-Campus as the Portal server, which of the following templates does not need to be configured?

URL template

Portal authentication template

Certification Template

DNMAC authentication template

116. Which of the following descriptions of WLAN network optimization measures is wrong?

If the threshold value for forcing users to go offline is too high, it will cause users to be easily disconnected. It is recommended to fine-tune it according to the actual situation of the project.

It is recommended to separate the AP management VLAN and user service VLAN

If multicast services are not planned in the network, it is recommended to configure multicast message suppression for both upstream and downstream

AP management VLAN and service VLAN can use VLAN 1

117. During the Portal authentication process, which of the following authentication request messages does the Portal server send to the access device?

HTTP POSTA

REQ AUTH

REQ CHALLENGE

HTTP GET

118. In the WAC+FITAP networking mode, which option field of the DHCP protocol can the AP use to discover the WAC device?

option 12

option 82

option 148

option 43

119. In the Portal authentication scenario, if there is no condition to deploy an external independent Portal server, the built-in Portal server of WAC can be used for authentication. Which of the following descriptions about the built-in Portal server is wrong?

Due to compatibility issues with some mobile browsers, Portal authentication users using these browsers will not be able to complete authentication.

The built-in Portal server does not support MAC-first Portal authentication

The built-in Portal server does not support custom authentication page content and style

Compared with the external Portal server, the built-in Portal server has simple functions and limited performance and is only suitable for scenarios with a small number of access users.

120. Which of the following descriptions of the Planner operation process about WLAN is correct?

Import drawings -> Create a new project -> Place APs -> Set up the environment -> Signal simulation

Create a new project->Import drawings->Set up the environment->Deploy APs->Signal simulation

Create a new project->Import drawings->Deploy AP->Set up environment->Signal simulation

Import drawings->Create a new project->Set up the environment->Deploy APs->Signal simulation

Page 13 of 20

121. The AP calculator in CloudCampus APP integrates various scenarios and network construction standards. Which of the following scenarios is not included?

Gaomi venues

Hotel

Mine

Shopping mall

122. In the VRRP hot backup scenario, restart the master WAC and AP switching is normal. After the original master WAC completes the restart, all APs are in fault state and the service is interrupted.

Which of the following could be the cause of this problem?

If the device is not configured with vrrp recover-delay, the restarted WAC may immediately become the master, resulting in a dual-master state.

The CAPWAP address between the active and standby WACs does not use a virtual address

Configuration synchronization is not enabled for the active and standby WACs

HSB is not enabled

123. Which of the following descriptions about WLAN network optimization is wrong?

During network optimization, you can use tools such as CloudCampus to evaluate network quality.

Before network optimization, network information needs to be collected, including network architecture, existing network configuration, and customer needs.

After network optimization is implemented and deployed, network optimization is completed after providing a network optimization solution report.

Before carrying out network optimization, a network optimization plan report needs to be output, and specific optimization will be implemented after customer confirmation.

124. WLAN Planner supports batch import of multiple drawings when creating a project, but there are restrictions on the drawing types. Which of the following drawing types does not support the batch import function?

OPNGA

JPG

PDF

CAD

125. Initially, if you use a network cable to connect to the AP, which of the following IP addresses can be used by default to log in and manage the AP?

169.254.1.1

169.254.2.1

192.168.1.1

192.168.2.1

126. During STA roaming, WAC will record the STA roaming track, that is, the AP information passed by.

Run the displaystationroam-track command on the WAC to view the STA's roaming track. Which of the following information is not included?

Negotiation rate between STA and AP

STA passes through AP's SSID

SSID that the STA is currently associated with

Name of the AP that the STA passes through

127. When using the CloudCampus app to test performance multiple times, the speed was 20 Mbps for three times, and then it reached 900 Mbps again. Which of the following configurations should be adjusted at this time?

[WAC-wlan-traffic-prof-default] scan-disable

[WAC-wlan-traffic-prof-default] sta-load-balancedynamic disable

[WAC-wlan-traffic-prof-default] rate-limit clientdynamic disable

[WAC-wlan-traffic-prof-default] calibrate auto-txpower-select disable

128. In the traditional operation and maintenance mode, daily maintenance is performed through the wireless controller web interface. Check the health of the AP on the wireless controller web interface to observe the overall status of the AP. The indicators that affect the health include the abnormal proportion of AP status, terminal access failure rate, disconnection rate, and number of access users. When the number of access users on a single AP exceeds how many, it will affect the health?

129. Initially, if you use a wireless connection to an AP, which of the following IP addresses can be used by default to log in and manage the FITAP?

192.168.1.1

169.254.2.1

192.168.2.1

169.254.1.1

130. When drawing obstacles using WLAN Planner, which of the following keys can be held down to make the obstacles straight lines?

Alt

Tab

Ctrl

Shift

Page 14 of 20

131. Which of the following is not a design principle for outdoor AP coverage when planning a WLAN network?

Directional APs or antennas are recommended for roads around buildings

Outdoor omnidirectional antennas need to be installed horizontally

The recommended installation height for outdoor directional and omnidirectional antennas is 3-5 meters

Omnidirectional antenna coverage is recommended for open scenes such as squares or parks

132. Among the following WAC backup solutions, which one has the fastest master-slave switchover speed?

Dual-link cold backup A

N+1 backup

VRRP hot backup

Dual-link hot backup

133. A Huawei AP supports the Wi-Fi 6 protocol. In dual-radio mode, the maximum MIMO number of the 5G radio can reach 8. When the 5G radio is configured to work at 160MHz bandwidth and accesses a terminal that supports the Wi-Fi 6 protocol, 160MHZ bandwidth and 2x2 MIMO number, what is the maximum theoretical rate of the terminal?

2.4 Gbps

1.2 Gbps

4.8 Gbps

9.6 Gbps

134. Which of the following descriptions of Huawei terminal plug-in test solutions is wrong?

The terminal needs to install a special "dial test APP" on the mobile phone to collect data

CampusInsight is used as the background analysis tool, which is responsible for receiving and analyzing the data reported by the AP

Terminal dial test is a test method for network link quality, which detects Wi-Fi user experience, network quality, link status and other information

Xserver acts as a data site, providing intranet test platform, vMos test plug-in, etc.

135. In the WAC high-reliability networking mode, which of the following is correct when sorting the active/standby switching speed from fast to slow?

N+1 backup > VRRP hot backup > dual-link hot backup / dual-link cold backup

VRRP hot backup > dual-link hot backup/dual-link cold backup > N+1 backup

VRRP hot backup > N+1 backup > dual-link hot backup/dual-link cold backup

Dual-link hot backup/dual-link cold backup > VRRP hot backup > N+1 backup

136. Which of the following descriptions about roaming groups in inter-WAC roaming solutions is wrong?

A maximum of 16 AC members can be added to a roaming group. The same WAC can join multiple roaming groups at the same time.

Roaming group names must remain consistent between WACs

When configuring a roaming group, ensure that the WAC has been configured with the CAPWAP source address, otherwise the roaming group will not take effect.

WACs in the same roaming group must use the same software version, otherwise roaming between WACs may fail.

137. In a VLAN network, which of the following descriptions about high-density network planning is wrong?

Before calculating the number of APs, you need to inspect and check the venue structure in advance.

High-density scenario is a coverage-limited scenario

High-density scenario is a capacity-limited scenario

In high-density scenarios, there are many APs, and the distance between APs needs to be controlled to reduce interference.

138. WAC can switch to cloud mode by switching the registration center. By default, what are the domain name and port number of the registration center preset by TAC?

139. In a Mesh network, which of the following node roles can connect the Mesh network to other types of networks?

Peer MP

MPP

Neighbor MP

140. Wireless communication allows only one device to send messages on a channel at the same time. Wireless terminals are in a competitive relationship. In order to prevent bandwidth resources from being monopolized by a certain terminal, user-based speed limits can be configured to solve the problem. For example, it is recommended to limit the terminal speed in multi-user and high-density scenarios.

The configuration for enabling user rate limiting on the wireless controller is as follows. Which of the following configuration descriptions is wrong? [WAC-wlan-view] traffic-profile name wlan-traffic

[WAC-wlan-traffic-prof-wlan-traffic] rate-limit client up 2048

[WAC-wlan-traffic-prof-wlan-traffic] rate-limit client down 3072

[WAC-wlan-traffic-prof-wlan-traffic] quit

The total uplink rate of all terminals under a VAP is limited to 5 Mbps

The uplink rate of each terminal is limited to 2 Mbps

The above speed limit configuration is effective for all terminals under the VAP bound to the traffic template.

The downlink rate of each terminal is limited to 3 Mbps

Page 15 of 20

141. When the engineer was inspecting the customer's wireless network, he found that the terminal failed to access the wireless network.

The possible reasons for the terminal online failure are checked through the CampusInsight protocol playback function. The terminal protocol playback is shown in the figure. Which option is wrong in the description of the terminal online failure?

Repair suggestion: Try to ping the authentication server to check whether the physical link of the authentication server is connected.

Repair suggestion: Check whether the RADIUS server template configuration parameters are consistent with the actual configuration on the RADIUS server.

The terminal has obtained an IP address through DHCP, but a failure occurs during the subsequent authentication phase

The most likely cause of the terminal going online failure is that the RADIUS server is unreachable.

142. In a WLAN network, which of the following descriptions about roaming is wrong?

The re-authentication process may not occur when the user is roaming

User access rights remain unchanged before and after roaming

Users will notice service interruption during roaming

The user's IP address does not change before and after roaming

143. In a WLAN network, there is a Wi-Fi 6 AP with 12 antennas. How many spatial streams can the AP support at most?

144. WLAN network optimization can be divided into the following stages: information collection, WLAN network evaluation, WAN network optimization solution design and network acceptance.

Which of the following descriptions about network evaluation is wrong?

You can use CloudCampus APP and eDesk tools to assist in network assessment

The main contents of network assessment include known problems of the existing network, wired network data, air interface performance data, etc.

Prepare a customer demand checklist in advance and verify the demand with the customer to avoid omissions

Network assessment does not require customer participation, and network status information is obtained through manual troubleshooting, tool inspection, etc.

145. The maximum number of layers supported by the location topology in Huawei eSight network management is () layers

146. Which of the following rates is not supported by the 802.11a protocol?

30Mbps

147. In WLAN networks, there are currently three main different PoE standards, namely () () ().

802.3af | 802.3at | 802.3bt

148. In the 802.11 frame, the terminal needs to send () control message to obtain access to the wireless medium.

RTS

149. When using the CloudCampus app to test WLAN network quality, you can test WLAN network coverage, service experience, and network)

Stability

150. In a WDS point-to-point network, the backbone link between the Root AP and the Leaf AP uses the 5GHz frequency band for connection. The frequency band used by the Root AP is 149. Then the Leaf AP needs to use the following () frequency band

149

Page 16 of 20

151. In the 80211 frame, STA's association request and authentication request belong to which type of frame?

Management Frame

152. 80211 The longest interval between frames is

DIFS

153. As shown in the figure, this is a WLAN network diagram of an enterprise. STA performs Layer 3 roaming in WAC, and the data forwarding mode is direct forwarding. At the same time, the user's home agent is configured on WAC. After STA roams, which of the following is the traffic forwarding path?

STA->AP2->SW>Internet

STA->AP2->WAC->Sw->Internet

STA->AP2->WAC->AP1->WAC->Sw->Internet

STA->AP2->WAC->AP1->SW->Internet

154. As shown in the figure, this is a schematic diagram of AP channel planning for a certain enterprise floor, and the planning has been completed for some floors.

It has been confirmed that the 2.4G frequency band channels will be used for deployment, and co-channel interference must be avoided. Which of the following is the most reasonable channel planning for the third floor?

13, 2, 7

1, 6, 11

6, 11, 1

5, 9, 1

155. An enterprise is deploying a WLAN network. In order to ensure business reliability, the wireless controller adopts dual-link hot backup networking.

It is found that dual links cannot be established between the active and standby WACs. The display ac protect command is executed on the active WAC, and the following output is displayed.

According to the analysis of the echo information, which of the following may be the cause of this phenomenon?

The dual-link switch on the standby WAC is not enabled

The primary WAC IP address is not configured on the standby WAC

The backup WAC IP address is not configured on the primary WAC

The backup WAC does not start normally

156. As shown in the figure, this is a WLAN network diagram of an enterprise. STA roams at layer 3 between TACs, and the user data forwarding method is tunnel forwarding.

By default, which of the following is the traffic forwarding path after STA roaming?

STA->AP2->TAC2->TAC1->AP1->Switch1->Internet

STA->AP2->TAC2->TAC1->AP1->TAC1->Switch1->Internet

STA->AP2->7AC2->Switch2->Internet

STA->AP2->TAC2->TAC1->Switch1->Internet

157. As shown in the figure, it is a WLAN network diagram of an enterprise. STA performs Layer 3 roaming in TAC, and the user data forwarding mode is direct forwarding. Then, by default, which of the following is the traffic forwarding path after STA roaming?

STA->AP2->WAC->AP1->WAC->sw->Internet

STA->AP2->SW->Internet

STA->AP2->WAC->SW->Internet

STA->AP2->WAC->AP1->Sw->Internet

158. A company has deployed a WLAN network. In order to prevent too many users from fiercely occupying the wireless channel, the company has configured user CAC. The specific configuration of the RRN template is as follows. Which of the following descriptions of the configuration is wrong?

The threshold for the number of new users is 32

When the number of online users reaches 40, the AP begins to reject access requests from other new users.

The user number threshold for roaming users is 40

The signal threshold for prohibiting weak signal terminals from accessing is 25dB

159. As shown in the figure, this is the toolbar of WLAN Planner. Users can click these icons to perform quick operations when planning and designing WLAN networks.

Among them, when clicking the "Replace" icon, which of the following devices is not included in the replacement?

Switch

WAC

Obstacles

160. As shown in the figure, there are four users under the same antenna of an AP. They all need to transmit data. It is known that User1 has occupied the channel for 3 times and transmits a round of data for 2 times; User2 has occupied the channel for 4 times and transmits a round of data for 4 times; User3 has occupied the channel for 6 times and transmits a round of data for 6 times; User4 has occupied the channel for 7 times and transmits a round of data for 7 times. After the Airtime scheduling function is enabled, according to the Airtime scheduling mechanism, which of the following users will be prioritized for scheduling ?

User1

User4

User3

User2

Page 17 of 20

161. In order to expand the wireless coverage area and reduce the cost of wired deployment, an enterprise adopts Mesh networking architecture to deploy WLAN network.

After the deployment is complete, the engineer runs the display mesh whitelist-profile all command, which displays the following information.

Which of the following descriptions of this network is wrong?

The Mesh whitelist template "test" is referenced twice

Users need to add the physical MAC addresses of neighboring APs that are allowed to access in the Mesh whitelist template.

The Mesh whitelist template "default" is not referenced

By default, the system has created a Mesh whitelist template named "default"

162. As shown in the figure, this is a WLAN network diagram deployed by an enterprise using a Mesh networking architecture.

The network contains multiple devices. Which of the following devices has the portal function?

AP2

AP1

AP4

AP3

163. In the WLAN network intelligent roaming scenario, WAC will select the target AP that triggers the terminal to roam based on factors such as signal-to-noise ratio, access rate, and load balancing. The figure shows the selection process of the roaming target AP when the terminal supports the 802.11k protocol. Which of the following is correct?

②④①③⑤

②⑤①③④

②④①⑤③

②⑤①④③

164. In a WLAN network, when deploying APs with external antennas, the antenna signal coverage range can be controlled by adjusting the antenna azimuth and downtilt angle. Which of the following angles does the downtilt angle refer to?

The angle formed by the antenna pattern at 3db below the main lobe peak

The angle formed by rotating clockwise from the north to the direction of the antenna main lobe

The angle between the antenna main lobe direction and the horizontal plane

The angle formed by rotating counterclockwise from the north to the main lobe direction of the antenna

165. A government needs to deploy a WLAN network. The link authentication uses open system authentication, but the security requirements are extremely high. When engineers select security strategies, which of the following should they use first?

WPA3-802.IX

Static WEP

WPA/WPA2-PPSK

OWE

166. In a certain enterprise WLAN network, only when the access authentication security policy selects which of the following, the link authentication needs to use the shared key authentication method?

WPA/WPA2

Dynamic WEP

Open

Static WEP

167. In a certain enterprise office WLAN network, network engineers found that many APs were offline for a long time after being disconnected, or were offline again after being online.

Which of the following could be the cause of this failure?

The AP's peer device has SIP enabled, but the AP has not.

The AP is not assigned an IP address

Insufficient license resources

WAC does not support this AP type

168. During the demand collection phase of WLAN network planning, three types of information need to be obtained: basic requirements, business requirements, and installation requirements.

Which of the following information is not included in the business requirements?

Power distribution method

Field strength requirements

Terminal Type

Coverage area

169. When conducting a WLAN network planning project in China, the customer requires the deployment of multiple 2.4GHz band APs. Which of the following channels is usually used when planning channels for the entire network APs?

2, 7, 11

1, 6, 11

1, 5, 7

2, 8, 10

170. Wireless Mesh Network is a new type of dynamic self-organizing and self-configuring wireless network. The nodes in the network can automatically establish and maintain Mesh connectivity. The nodes of the Mesh link include MPP and MP nodes, which support different functions.

Which of the following functions does MPP have to enable communication between internal nodes of Mesh and external networks?

Automatic route discovery

Automatic Topology

Data message forwarding

Portal function

Page 18 of 20

171. When a large enterprise deployed a wireless network, it adopted the Navi AC networking architecture to avoid potential security threats to the network caused by visitor data.

Which of the following points about deploying the Navi AC function is wrong?

Local AC and Navi AC do not support compatibility between different versions

Roaming groups cannot be established between Navi AC and Local AC

Make sure that the DTLS pre-shared key configuration of Local AC and Navi AC is consistent

Does not support cross-Navi AC roaming

172. In WLAN networks, the Wi-Fi 6 standard has the advantages of large bandwidth, high concurrency, low latency, and low power consumption.

Which of the following technologies does Wi-Fi 6 use to reduce latency?

OFDMA technology

8x8 MINO spatial stream

BSS Color Technology

TWT technology

173. A company has deployed multiple APs in its office area. To improve the convenience of network deployment, the user hopes that WAC will automatically assign channels to APs based on the wireless network environment, so the RF tuning function is configured.

However, engineers found that the RF tuning did not take effect. Which of the following configurations might be the cause?

Configure the command calibrate Auto-charnel-select Disable

The radio-mode 2radio-independent-scan command is configured

Configure the command calibrate Auto-txpower select enable

Configure the command undo terminal-identify Disable

174. In the WLAN backhaul scenario, due to the complex environment and high bandwidth requirements of the business, reasonable planning is required when designing and installing APs.

Which of the following deployment suggestions for backhaul scenarios is wrong?

It is necessary to confirm in advance whether there are obvious obstacles on the propagation path between MP and MPP nodes.

Check in advance whether there is interference in the Wi-Fi frequency band near the site

The antenna installation height must be within the radius r of the building's high Fresnel zone

When selecting a directional antenna, the main lobe coverage of the MPP antenna should cover all MP antennas.

175. During the daily operation and maintenance of WLAN, an engineer found that the status of a certain interface of the wireless controller was abnormal. After troubleshooting, he suspected that the port negotiation mode was inconsistent. Which of the following commands can be used to check?

display Current-configuration interface

Display interface Brief

display ip Interface

display interface

176. In a certain enterprise office wireless coverage scenario, since the VIP area has high bandwidth requirements and requires the terminal signal strength to be lower than -65 dBm, the STA is forced to go offline directly.

Based on the above requirements, engineers configure the fast forced user offline function on the wireless controller. What should the SNR threshold be set to?

177. In intelligent operation and maintenance based on Canpusinsight, experience visualization management and minute-level potential fault identification and root cause location are provided. Among them, which of the following technologies supports experience visualization and uses HITP2+ProtaBuf to collect data from remote devices?

Telemetry

HITPS

KPI

SNMP

178. In an office scenario, 300 terminals are connected to the network, and 180 terminals generate service traffic at the same time. When both AP and terminal support Wi-Fi 6, the bandwidth requirement of a single terminal is 8Mbps. Under this bandwidth requirement, the tri-band AP (8x8 MINO) deployed can support 51 terminals (2x2 MIMO) concurrently. So for the above scenario, how many tri-band APs are needed to meet the capacity requirements of the WLAN network?

179. When the WLAN network project is delivered, you can use the Wi-Fi health check function in the ClouCampus APP to detect the current Wi-Fi network status.

This function will be tested in many aspects, but which of the following aspects are not included?

Coverage Test

Cybersecurity

Wi-Fi stability

Wi-Fi Capacity

180. In a WLAN network, for sticky terminals, which have poor roaming initiative, the roaming problem can be solved by configuring the smart roaming function in which of the following templates?

RRM template

SSID template

VAP template

Certification Template

Page 19 of 20

181. In order to isolate visitor traffic and employee traffic, a large enterprise adopted the Navi AC networking architecture to deploy a WLAN network.

When configuring Local AC, which of the following descriptions is wrong?

Navi AC must be specified

The service VLAN needs to be allowed on the interface

Create and configure a VAP template

Ensure that the DTLS pre-shared key configuration is consistent with that on Navi AC

182. In the Mesh networking of WLAN network, APs are connected by wireless. Compared with the traditional WLAN network where the AP uplink uses a wired network, which of the following is not an advantage of Mesh networking?

Low network construction cost

Good anti-interference ability

Flexible networking

Wide application scenarios, such as mines, docks, etc.

183. In order to prevent too many users from accessing the WLAN network and causing poor Internet quality, a company configured a user CAC function based on the number of users.

It is now required that after the number of access users reaches 25, the AP will reject access requests from other new users and hide the SSID. Which of the following configurations does not need to be configured?

[TAC-wlan rrm Prof-user cac] uac client Number enable

[TAC-wlan r r m Prof-user cac] uac client Number threshold access 25 roam 25

[TAC-wlan rrm Prof-user cac] uac Reach-access-threshold hide-ssid

[TAC-wlan rrm Prof-user cac] uac Client-snr threshold 25

184. The highest Wi-Fi standard of a certain indoor AP is 802.11ax, the MIMO number can reach 12-12:8, and it supports dual-radio and triple-radio modes.

Which of the following descriptions about the AP is wrong?

There are 12 antennas at the receiving end

Can use 2.4GHz and 5GHz bands at the same time

There are 12 antennas at the transmitting end

Supports up to 12 spatial streams

185. In actual projects, engineers often use the "Roaming Experience" function of the CiudCampus APP to detect changes in Wi-Fi information and roaming switching during mobile phone roaming.

This feature can be found in which of the following "Tools" pages of the CloudCampus app?

Business Testing

Scenario Testing

Coverage Test

Project Delivery

186. In the Mest network, it is composed of multiple nodes (APs), each providing different functions.

Which of the following descriptions about nodes is wrong?

MP provides Mesh services and has Portal functions

Neighbor MP is an MP or MPP that is in direct communication range with a Mesh node.

The candidate MP is the neighbor MP with which the MP is preparing to establish a Mesh link

MPP is an MP node that connects Mesh networks and other types of networks

187. A large enterprise uses Navi AC networking architecture to deploy LAN network. When engineers configure Navi AC function, which of the following authentication methods does not need to ensure that the authentication configuration on Local AC and Navi AC is consistent?

802.1X authentication

MAC Authentication

Built-in Portal authentication

External Portal Authentication

188. In the WLAN network, WLAN security provides a variety of security strategies, such as OPEN, WEP, WPA and WPA2, and each security strategy embodies a complete set of security mechanisms.

of the following security strategies has the strongest encryption?

WPA3

WEP

WPA2

WPA

189. A large enterprise needs to deploy a WLAN network. In order to achieve secure isolation between employee access and guest access, the Navi AC networking architecture is adopted. At the same time, when the enterprise engineer configures user authentication, the security policy is set to Open. Which of the following cannot be selected when configuring the authentication method?

Built-in Portal authentication

802.1X authentication

External Portal Authentication

MAC Authentication

190. When an enterprise deploys a WLAN network, user access authentication uses Portal authentication. After successful authentication, the network can be reconnected within a certain period of time without entering the user name and password to re-authenticate the portal. Which of the following authentication methods can the enterprise engineer choose to deploy?

External Portal server authentication

MAC authentication with Portal server

MAC-first Portal authentication

Built-in Portal server authentication

Page 20 of 20

191. A retail store has newly built a WLAN network. For the in-store barcode scanner business, users require multiple barcode scanners to connect to the same SSID, but each barcode scanner needs to be configured with a different key, and there is no need to deploy an authentication server. Which of the following authentication methods can engineers use to meet the above requirements?

WPA/WPA2-DPSK authentication

WPA/WPA2-PPSK authentication

Static WEP authentication

WPA/WPA2-802.1X authentication

192. When a company builds a new office network, it has 250 employees, a daily office bandwidth requirement of 8Mbps, a WLAN network concurrency rate of 60%, and uses dual-band AP networking (the number of concurrent users of a single AP under this bandwidth requirement is 30) to complete the deployment of the WLAN network. As the business develops, the company needs to recruit 200 more employees. How many more APs do they need to add to meet the wireless office needs?

193. Which of the following descriptions about PMK fast roaming are correct? (Multiple choice)

PMK fast roaming supports WPA3-802.1X or WPA2-802.1X authentication methods

PMK fast roaming does not require re-authentication and key negotiation, thus reducing roaming delays

PMK fast roaming requires the client to support fast roaming technology

PMK fast roaming is achieved through pairwise master key PMK caching technology

194. In a wireless network, when a STA moves from one AP coverage area to another AP coverage area, WLAN roaming technology can be used to achieve smooth switching of terminal user services.

Which of the following conditions must be met to achieve roaming between two APs? (Multiple choice)

Configure the same service VLAN

Configure the same data forwarding mode

Configure the same SSID

Configure the same security policy

195. Which of the following options are correct in describing Huawei's smart roaming solution? (Multiple choice)

Through intelligent roaming, each terminal is ensured to be associated with the AP closest to it, achieving load balancing between APs

For normal coverage scenarios. By roaming terminals with poor signals to APs with better signals, the service experience of the terminals themselves and the overall performance of the wireless channel are improved.

Smart roaming solution is proposed to reduce roaming switching time

Smart roaming can significantly improve wireless channel performance by associating the terminal to an AP with better signal.

196. During the acceptance of the customer's wireless network, the engineer found that the terminal roaming failed. Which of the following situations may be the cause of the terminal roaming failure? (Multiple choice)

The customer's existing network is a Layer 3 roaming scenario, but the device is configured to prohibit Layer 3 roaming

AP signal coverage is discontinuous and there are blind spots

The user forwarding methods configured on the two roaming APs are inconsistent

The security template names configured on the two roaming APs are inconsistent

197. Which of the following options are correct in describing Huawei's RF tuning solution? (Multiple choice)

The RF tuning function has three modes: automatic tuning mode, manual tuning mode, and timed tuning mode. However, the three working modes are mutually exclusive. Users can choose one according to their actual situation.

The radio tuning function does not take effect for radios configured with WDS bridges or Mesh links.

RF tuning can be done in two ways: global tuning and local tuning.

Neighbor detection methods include active detection and passive detection

198. Which of the following options are correct for describing the spectrum navigation function? (Multiple choice)

When the number of users accessing the AP reaches the starting threshold of spectrum navigation 5G priority, the 2.4G radio frequency is silent and the terminal is guided to access 5G

Through the spectrum navigation function, the AP can control the terminal to access 5G first to reduce the load and interference on the 2.4G frequency band

Before the number of AP users reaches the starting threshold of spectrum navigation 5G priority, priority access to the 5G frequency band

The two frequency bands of the AP that implement the spectrum navigation function must use the same SSID and security policy

199. In a WLAN network, the working status of the AP will be affected by the surrounding environment. By dynamically adjusting the AP's channel, power, and frequency band, each AP managed by the same TAC can ensure coverage while avoiding interference as much as possible, ensuring that the AP works in the best state. Which of the following are solutions supported by Huawei's wireless radio frequency automatic tuning? (Multiple choice)

Dynamic frequency band adjustment

Dynamic Bandwidth Selection

Dynamic Power Scaling

Dynamic channel adjustment

200. When using the AP calculator in the CloudCampus app to quickly calculate the number of APs in a mobile office scenario, which of the following parameters should be entered based on actual conditions? (Multiple choice)

Number of rooms

AP Concurrency Rate

Single-user bandwidth requirements

Deployment area

H12-323_V2.0 HCIP-WLAN V2.0 Exam Dumps

H12-323_V2.0 HCIP-WLAN V2.0 Exam Dumps

Share this post

Related Posts
